Product Features

SMART-PSS

  • Support IPC, DVR, NVR, NVS, video wall controller, NKB, VTO and etc
  • Live preview
  • Support up to 64*4 preview windows; main/sub stream optional.
  • Support tour task.
  • Auto find/import/export supported; easy to manage up to 256 devices or 2000 channels.
  • Max 36-channel synchronization playback. Time bar and event modes optional.
  • Joystick to control PTZ and zoom in/out and fish-eye camera EPTZ using mouse.
  • Center alarm for organizing alarm channels as whole associated system.
  • Support e-map; you can clearly view and manage all device locations.
  • PC-NVR feature provided for saving cost.
  • TV wall configuration and control.
  • Four sub modules of video talk supported as monitor, talk, announcement and configuration.
  • Account management supported; and different users share different privileges.
  • Log for event and user operation.
  • Friendly GUI for an easy operation.
  • Support P2P.
  • Support fisheye dewarp of the latest fisheye IPC in preview and playback.

DESCRIPTION

Version Windows Version 1.12.3 MAC Version 1.11.1
Supported Devices DVR, NVR, IPC, NVS, Video Wall Controller, NKB, VTO and etc. DVR, NVR, IPC, NVS, Video Wall Controller, NKB and etc.
Management Devices Max 256
Management Channels Max 2000
Device Management Auto find, Add, Delete, Device group, Reboot, Setup, Specify network segment
Health Report Device status, Alarm info, HDD info
Video Display Split 1 / 4/ 6/ 8 / 9 / 16 / 25 / 36 or customized split for all versions 64 is only available for windows version
Max Preview Screen 4 1
Features Snapshot, Record, Audio, Talk, Instant playback, E-PTZ, Tour task, View, Fisheye dewarp, IVS, Stream control, Optional video scale Snapshot, Record, Audio, Talk, Instant playback, E-PTZ, Tour task, View, Stream control, Optional video scale
PTZ Control Directions, PTZ, Focus, Iris, Preset, Tour, Pattern; Joystick control
Alarm output control Support
PC_NVR 32 Channels using window’s PC_NVR
Record Mode Manual, Schedule(Regular, MD, Alarm), Stop
Video Source Local PC (Manual record or alarm record), Device itself, PC-NVR
Picture Source Local PC (Manual Snapshot), Device itself
Max Channels 36
Duration 24h for one search
Search Type Certain time, Motion detection, Alarm, Smart search, Call ID
Max task of Export 10 once
Features Snapshot, E-PTZ, Audio, Speed 1/8x~8x, Faster/Slower play, Synchronization playback, Fisheye Dewarp, Optional video scale Snapshot, E-PTZ, Audio, Speed 1/8x~8x, Faster/Slower play, Synchronization playback, Optional video scale
Export Export as .dav/.avi/.mp4/.asf Export as .dav
Features Schedule alarms, Setup actions, Operate/Memo alarm
Alarm Type External alarm, Video loss, Motion, Tampering, Disk full or Error
Actions Trigger recording, PTZ movement, Alarm, Popup video
Number of Maps Map group : Unlimited, Sub-Map, Layout : 64
Image Format JPEG / BMP
PC-NVR 32 channels record
Device Config Network, Encode, PTZ, Image, Event, Record, Disk, Account, Maintenance, Web
Display Remote control device’s local splits
Account User and role management; privileges according to module & device.
Log Client log, Remote device log, Operation log, System log, Alarm log
Video Talk Preview, Talk, Unlock, Call, Record, Announcement, Config, Snapshot
System Requirement CPU: 2 cores, 3.0GHZ or above; Memory: 2G or above; HDD 80G or above
OS Window XP/Vista/7/8 OS 10.7 or above
Display resolution 1024 x 768 or above(for advance)
